Products Description
oplus_262176
| Product Name | Carel E6VB2ASV00-C Stepper Electronic Expansion Valve |
| Model | E6VB2ASV00-C |
| Applicable Industries | Construction and Commercial |
| Application | Refrigeration compressor |
| Packaging | Cardboard Box |
| MOQ | 1 Piece |
Internal structural materials and composition
Forged brass valve body (pressure-bearing main component) with an integrated side-mounted sight glass;
Stainless steel tapered precision throttling valve core (flow regulation core);
PTFE composite valve seat seal ring (zero-leakage, bi-directional pressure capability);
Stainless steel drive spindle connecting the stepper motor to the valve core;
Bipolar low-voltage sealed stepper motor coil assembly;
4-core shielded oil-resistant control cable with a waterproof locking connector.
Tags: #AirConditionerValve #CarelElectronicExpansionValve #ChillerParts #CommercialRefrigeration #CoolingSystemComponent #E6VB2ASV00-C #ElectronicExpansionValve #HVACSpareParts #IndustrialHVACParts #RefrigerantControlValve #RefrigerationCompressorAccessory #RefrigerationMeteringDevice
Technical parameter
Company Profile
Factory Profile
| Q1:For refrigeration industry, which brands are your products covering? | A1:We produce filter element replacements for brands like,Bitzer, Carrier, Yk, McQuay, Trane, etc… |
| Q2:Does the price include freight? | A2:The quotation is usually the factory price. We can recommend the most economical logistics plan and calculate the freight according to your destination and quantity. |
| Q3:How to ensure product quality? | A3:We have a strict quality control process, and we will carry out multiple inspections before the products leave the factory to ensure that they meet the standards. |
| Q4:Why choose us? | A4:Product reliability: We are a professional manufacturer . can offer high-quality products at the most competitive prices. Technical support: We provide technical assistance. Industry experience: We have over 10 years of experience in the refrigeration equipment service field. After-sales service: We offer professional after-sales service. Team collaboration: We have a professional team that can provide you with prompt services and delivery schedules. |
Core Performance Advantages
Precision Linear Throttling Across Full 500-Step Range
Offers stepless, continuous adjustment from 0 to 480 steps, maintaining stable superheat (4–6K). Automatically reduces valve opening at low loads to prevent liquid hammer and fully opens at peak loads to ensure adequate refrigerant circulation, balancing cooling capacity with compressor protection.
Integrated Sight Glass—No Add-on Required
Features a built-in sight glass on the valve body, eliminating the need to purchase and install a separate line-mounted sight glass. Allows for intuitive on-site diagnosis of refrigerant charge levels, filter-drier failure, and system moisture issues, while reducing piping component costs.
Wide Differential Pressure & Multi-Refrigerant Compatibility
Withstands pressure differentials up to 28 bar and is compatible with R410A (high-pressure air-cooled), R134a (water-cooled), and low-temperature R404A (refrigeration) units, ensuring excellent spare part versatility.
4-Wire Shielded Stepper Drive—No Step Loss in Inverter Systems
Shielded cabling isolates high-frequency interference from inverters and contactors; valve opening remains drift-free during load fluctuations, preventing issues such as evaporator icing or frequent high-pressure trips.
High-Pressure Resistant PTFE Composite Seal—Leak-Free Durability
The valve seat seal is compatible with high-pressure refrigerants and POE oils, ensuring zero micro-leakage during long-term full-load operation and reducing the need for annual refrigerant top-ups.
